C.Scope DXL3 Cable and Pipe avoidance tool

The C.Scope DXL3 depth measurement cable locator is a durable and affordable industry-standard locating device designed to detect underground pipes and cables before excavation work begins.

Damaging buried services during excavation is costly and can be extremely dangerous. The C.Scope cable locator is an ideal and easy-to-use tool for quickly and reliably locating buried pipes and cables, time after time. Safe, simple, fast, and reliable.

The C.Scope cable locator features three familiar detection modes (Power, RADIO, and Transmitter) to choose from. Each mode offers its own specific advantages, and many users are already familiar with using these modes:
- Power mode is the fastest way to detect most buried electrical cables by detecting the signal created by the electrical current itself.
- Radio mode detects retransmitted radio signals in metal pipes and cables, allowing their location to be determined using only the cable locator.
- Transmitter mode detects the signal sent by the C.Scope SGA3 signal generator to a metal pipe or cable. Additionally, the generator mode can also be used to trace non-metallic pipes with the C.Scope sonde.

Depth measurement on the DXL3 cable locator is simple with a depth measurement button located on the top of the product (to be used in TRANSMITTER MODE).

When combined with the C.Scope SGA3 signal generator and accessories, the cable locator becomes a versatile and comprehensive package for locating and tracing pipes and cables. Its durable construction, LCD meter, detachable speaker, and easy fingertip controls make the C.Scope cable locator an ideal tool for workers of all levels who need a reliable way to quickly and accurately detect underground services.

Calibration: The DXL3 cable locator requires annual calibration.

Controls:
- Power switch: Spring-loaded trigger switch under the handle
- Mode selection switch (three-position): - P - Power mode - R - Radio mode - G - Transmitter mode - Sensitivity adjustment
- Depth button: Button for real-time depth display
- Audible signal: Detachable and user-replaceable speaker module

Visual display: Multi-segment liquid crystal display (LCD) showing:
- Signal strength
- Selected operating mode
- Battery status
- Depth measurement (in transmitter mode)

Technical specifications:
- Weight (including batteries): 2.9 kg
- Dimensions: 720 mm x 270 mm x 63 mm
- Housing made of impact-resistant plastic designed to withstand a 1-meter drop onto a hard surface.
- IP65: Dust and water jet protection

Performance:
- Locating accuracy: Better than 10% of depth
- Depth accuracy: ±5% @ 1 m
- Lines: 0.2 m - 3 m
- Sondes: 0.85 m - 4.5 m depending on sonde type

- Depth accuracy:
- Lines: 0.05 m
- Sondes: 0.15 m

Batteries:
- Type: Internal 8 x 'AA' (LR6) batteries (either alkaline or rechargeable NiMH batteries)
- Battery life: 40 hours of intermittent use at 20 °C using alkaline batteries

Warranty: 3 years
